Filleting machine Baader 35 Nº ID-1915

The BAADER 35 can process herring, spiced herring, salt herring from 20-40cm (75-450g), mackerel and silver smelt 24-40cm (130-600g), blue whiting 22-40cm (75-350g) as well as trout 25-38cm (160-600g).

Year: 1990

Dimensions aprox: 3300 x 1250 x 1800 mm

MANUFACTURER TECHNICAL DATA

Can be combined with Automatic feeder, Baader 488. See complete line HERE.

Filleting machine for mackerel, VMK, Nº  ID-2295

Material: Stainless steel

Power supply: 220/380 V, 50/60 Hz

Total dimensions: 2540 x 1150 x 1900 mm

Filleting machine Baader tpye: 184, Nº ID-1885

Machine number: 10.3320 0184

Year: 1983

Power supply: 380 V, 3 Ph, 50 Hz, 11.5 kW, 22.0 A

Plastic conveyor belt width: 500 mm

Band width: (2x) 160 mm

Throughput: 24-40 pieces/min

Water consumption: 25 l/min

Weight: 2.500 kg

Dimensions: 5400 x 1300 x 1450 mm

MANUFACTURER TECHNICAL DATA

Filleting machine for mackerel, VMK, Nº  ID-2294

Belt width:70 mm

Power supply: 220/380 V, 50/60 Hz

Total dimensions: 2360 x 800 x 1680 mm
