FISH AND SEAFOOD MACHINERY 161 products.

AUTOMATIC PROCESS MACHINE FOR LIQUIDS FOODS, KARL SCHNELL TIPO: 250

Machine number: 25162

Year: 2001

Two knives

Nominal volume: 300L

Dimensions: 1500 x 1150 x 2350 mm

MANUFACTURER TECHNICAL DATA

HOPPER WITH BUCKET LIFT CONVEYOR, ID 1678

Band width: 360 mm

Bucket height: 100 mm

Distance between buckets: 310 mm

Lift height: 2.750 mm

Dimensions: 3400 x 1280 x 2850 mm

SHELL SHREDDER  MACHINE,  ID 2175

Tank size: 500 x 380 mm

Material: Stainless steel

Dimensions: 700 X 850 X 1900 mm

DISK SEGMENTATION SAW, BANKERYDS MASKIN AB TYPE: RS750 ID 2147

Serial number: 5368

Year: 2004

Power supply: 400V, 3 Ph, 50 Hz, 3.65 A, 1.5 kW, 48 R/m

Weight: 360 Kg

Blade diameter: 740 mm

Dimensions: 1650 x 850 x 1670 mm

FORMING MACHINE CFS, TIPO: MLF 400 ID-2161

Serial number: 2234

Year: 2003

Power supply: 400 V, 3 Ph, 50 Hz, 17.75 A, 7.77 kW

Weight: 1186 kg

Hopper size: 750 x 800 x 650 mm

Format: Ø 85 mm

Working width: 400 mm (Stainless steel mesh)

Dimensions: 2550 x 860 x 2500 mm

MANUFACTURER TECHNICAL DATA

Complete line composed of:

Forming machine CFS MLF400, Battering,flouring machine and feed hopper MEYN.. HERE

Heading machine for salmon, cod, tuna and more.. PISCES IND. type: HV-40, Nº ID-2038

Serial number: 2124

Year: 2014

Conveyor width: (2x) 190 mm

Blade diameter: 400 mm

Power supply: 380/440 V - 50/60 Hz

Dimensions: 2300 x 1600 x 1700 mm

MANUFACTURER TECHNICAL DATA

Bowl cutter Kramer+Grebe, type: SM45 STL, Nº ID 2140

Serial number: 258/108 82

Bowl capacity: 45 Liters (Stainless steel)

Power supply: 380/220 V, 3 Ph, 50 Hz

Dimensions: 1480 x 1020 x 1170 mm

MANUFACTURER TECHNICAL DATA

PEELER- SKINNER, TRIO, type: FDS 104 Nº ID 2132

Year: 2000

Plastic wired belt

Belt width: 350 mm

Power supply: 380/440 V - 50/60Hz

Dimensions: 2200 x 1200 x 1500 mm

MANUFACTURER TECHNICAL DATA

The TRIO FDS Skinning Machine will skin most kind of fish fillets. The machines are used for skinning Sale and other flat fish, Hake, Haddock, Whiting, Merluza, Hoki, Orange Roughy, Herring, Mackerel, Sardines, Salmon, etc.

Filleting machine Baader 35 (single or butterfly fillet) Nº ID-1999

The BAADER 35 can process herring, spiced herring, salt herring from 20-40cm (75-450g), mackerel and silver smelt 24-40cm (130-600g), blue whiting 22-40cm (75-350g) as well as trout 25-38cm (160-600g).

Machine number: 10-1363-0035

Year: 1992

Throughput rate: 160-250 pieces/min

Voltage/Power:  380 V, 3 Ph, 50 Hz, 11 A

Dimensions aprox: 3950 x 2600 x 1550 mm

Weight: 835 Kg

MANUFACTURER TECHNICAL DATA

Storage silo with mixer 2.500 liters, Nº ID 1546

Material: Stainless steel

Power supply: 380/440 V - 50/60Hz

Diameter: 1300 mm

Height: 2000 mm

Capacity: 2.500 lt

Dimensions: 1600 x 1600 x 3200 mm

Fish scaling machine, Mecalsa tipo: MC EC-SA, Nº ID 1554 (special for sardine)

Material: Stainless steel AISI 316

Voltage-Frequency: 380/440 V - 50/60Hz

WASHING AND SCALING CORPS

(DISINFECTION AND FINAL WASHING CORPS TO BE INCORPORATED)

Separator, Sepamatic, type: SEPA 410 ST, ID 1732

Throughput rate: up to 800 Kg/h according to product

Drum: 2 or 5 mm

Power: 2,5 Kw

Power supply: 380-440 V/50-60 Hz

Dimensions: 1400 x 700 x 1600 mm

MANUFACTURER TECHNICAL DATA
